| Video/Audio Input |
|---|
| Audio Input: | 16-ch |
| Video Compression: | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Analog and HD-TVI video input: | 32-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
| Supported camera types: | Support HDTVI input: 8 MP, 5 MP, 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60
Support AHD input: 5MP,4MP,1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz
Support CVI input: 4 MP, 1080p25, 1080p30, 720p25, 720p30
support CVBS input |
| Audio Compression: | G.711u |
| Audio Input Interface: | RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input) |
| Video/Audio Output |
|---|
| HDMI2 Output: | 1-ch,4K(3840 × 2160)/30Hz,2K(2560 × 1440)/60Hz,1920×1080/60Hz,1280 × 1024/60Hz,1280 × 720/60Hz, 1024 × 768/60Hz |
| HDMI/VGA Output: | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| Recording resolution: | 8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF |
| Frame Rate: | Main stream:
8 MP@8fps/5 MP@12fps; 4 MP@15fps; 3 MP@18fps;
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)
Sub-stream:
WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Video Bit Rate: | 32 Kbps-10 Mbps |
| Stream Type: | Video/Video&Audio |
| Two-way Audio: | 1-ch, RCA (2.0 Vp-p, 1 kΩ) (independent) |
| Audio Output: | 2-ch, RCA (Linear, 1 kΩ) |
| Dual Stream: | Support |
| Synchronous Playback: | 16-ch |
| Network management |
|---|
| Remote connections: | 128 |
| Network protocols: | TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP?, HTTPS,ONVIF |
| Hard Disk Driver |
|---|
| Interface Type: | 8 SATA Interfaces |
| Capacity: | Up to 10 TB capacity for each disk |
| e-SATA Interface: | 1 eSATA interface |
| Disk Array |
|---|
| Array Type: | RAID0, RAID1, RAID5, RAID6,RAID10 |
| External Interface |
|---|
| Network Interface: | 2; 10M / 100M / 1000M self-adaptive Ethernet interfaces |
| USB Interface: | 2 USB 2.0 Interface on the front panel& 1 USB 3.0 Interface on the rear panel |
| Serial Interface: | 1 RS-232 serial interface
1 RS-485 serial interface, full-duplex,1 RS-485 keyboard interface |
| Alarm Input: | 16-ch |
| Alarm Output: | 8-ch |
| General |
|---|
| Power Supply: | 100 to 240 VAC |
| Consumption: | ≤ 74W(without hard disks) |
| Working Temperature: | -10 oC to +55 oC (+14 oF to +131 oF) |
| Working Humidity: | 10% to 90% |
| Dimensions: | 442 × 470 × 90 mm (17.4 × 18.5 × 3.5 inch) |
| Weight: | ≤ 10 kg (22.0 lb) |
