| System Parameters |
|---|
| Operation System: |
Embedded Linux Operation System |
| Flash: |
32MB |
| Memory: |
128MB |
| Display Parameters |
|---|
| Display Screen: |
7-inch colourful IPS LCD |
| Display Resolution: |
1024 × 600 |
| Operation Method: |
Capacitive Touch Screen, Physical Button |
| Audio Parameters |
|---|
| Audio Input: |
Built-in Omnidirectional Microphone |
| Audio Output: |
Built-in Loudspeaker |
| Audio Compression Standard: |
G.711 U |
| Audio Compression Rate: |
64 Kbps |
| Audio Quality: |
Noise Suppression and Echo Cancellation |
| Network Parameters |
|---|
| Wired network: |
10/100 Mbps self-adaptive network |
| Wireless network: |
Wi-Fi 802.11b/g/n |
| Network Protocol: |
TCP/IP, SIP, RTSP |
| Network interface: |
1 RJ-45 10/100 Mbps self-adaptive |
| Device Interfaces |
|---|
| I/O Output: |
2 |
| Alarm Input: |
8-ch alarm inputs |
| RS-485: |
Supported |
| TF Card (micro SD card): |
Max to 32 G, SD 2.0 or lower version |
| General |
|---|
| Power Supply: |
IEEE802.3af standard PoE, 12 VDC/1A |
| Power Supply via Detector: |
12 V, 200 mA |
| Power Consumption: |
≤7W |
| Working Humidity: |
10% to 90% |
| Working Temperature: |
-10° C to + 55° C (14° F to 131° F) |
| Dimensions(L × W × H): |
180 mm × 140 mm × 22.4 mm (7.09" × 5.51"× 0.88") |
| Certification: |
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE, UL, CB, RCM |
