| Camera |
|---|
| Image Sensor: |
1/2.5" progressive scan CMOS |
| Effective Pixels: |
2560(H)×1440(V) |
| Signal System: |
PAL/NTSC |
| Minimum Illumination: |
Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR |
| White Balance: |
Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| AGC: |
Auto/Manual |
| BLC: |
ON/OFF |
| HLC: |
Support |
| Smart defog: |
Support |
| WDR: |
120dB |
| Shutter Time: |
1/1 to 1/30,000s |
| Day& Night: |
ICR |
| Digital Zoom: |
16× |
| Auto Focus: |
Auto / Semi-automatic / Manual |
| Lens |
|---|
| Focal Length: |
4.8 mm to 120 mm, 25× optical |
| Zoom Speed: |
Approx. 3.2 s (optical lens, wide-tele) |
| Angle of View: |
Horizontal field of view: 57.6° to 2.5° (wide-tele)
Vertical field of view: 34.4° to 1.4° (wide-tele)
Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Minimum Working Distance: |
10 to 1500mm (wide-tele) |
| Aperture Range: |
F1.6 to F3.5 |
| Pan & Tilt |
|---|
| Pan Range: |
360°endless |
| Pan Speed: |
Configurable, from 0.1°/s to 300°/s
Preset Speed: 350°/s |
| Tilt Range: |
-5°~90° (Auto Flip ) |
| Tilt Speed: |
Configurable, from 0.1°/s to 160°/s
Preset Speed: 200°/s |
| Proportional Zoom: |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: |
300 |
| Patrol: |
8 patrols, up to 32 presets for each patrol |
| Pattern: |
4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory: |
Support |
| Park Action: |
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| PTZ Position Display: |
ON/OFF |
| Infrared |
|---|
| IR irradiation distance: |
50m |
| IR irradiation angle: |
Adjustable by zoom |
| Alarm |
|---|
| Alarm Input: |
2 |
| Alarm Output: |
2 |
| Alarm Actions: |
Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
| Input & Output |
|---|
| Audio Input: |
1-ch audio input |
| Audio Output: |
1-ch audio output |
| Network |
|---|
| Ethernet: |
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
2560 × 1440 |
| Main Stream: |
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
50fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: |
50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Third Stream: |
50Hz: 25fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression: |
Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG |
| Audio Compression: |
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| No. of Simultaneous Users: |
Up to 20 users |
| Three-Stream: |
Support |
| Mini SD Card: |
Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Security Measures: |
User Authentication (User ID and Password), Host Authentication (MAC address), HTTPS Encryption, IEEE 802.1x Port-Based Network Access control, IP address Filtering |
| Client GUI |
|---|
| Client: |
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect |
| General |
|---|
| Power Supply: |
12VDC, PoE+ |
| Power Consumption: |
Max.: 18W (IR light 5W Max.) |
| Working Temperature/Humidity: |
Outdoor: -30°C to 65°C (-22°F to 149°F)
Humidity:≤ 90% |
| Protection Level: |
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Dimensions: |
Φ 169 mm × 161 mm (Φ 6.65" × 6.34") |
| Weight (approx.): |
Approx. 2.45kg (5.40lb) |
