| Video/Audio input |
|---|
| Video Compression: |
H.264/MPEG4/MPEG2/MJPEG |
| Video input: |
1-ch,
BNC (1.0 Vp-p, 75 Ω) 4-ch,
BNC (1.0 Vp-p, 75 Ω) |
| Audio compression: |
G.711 |
| Audio input: |
1-ch, 3.5mm interface
(2.0 Vp-p, 1 kΩ) 4-ch,
Line input interface
(2.0 Vp-p, 1 kΩ) |
| Two-way audio: |
1-ch, 3.5 mm audio (2.0 Vp-p, 1 kΩ) |
| Video/Audio output |
|---|
| Audio output: |
1-ch, 3.5mm interface (Linear, 600 Ω) |
| Encoding resolution: |
WD1/4CIF/2CIF/CIF/QCIF |
| Frame rate: |
H.264/MPEG4/MPEG2 encoding: 25 fps (P) / 30 fps (N); MJPEG encoding: 15 fps |
| Video bit rate: |
32 Kbps ~ 3072 Kbps, or user defined (Max. 8192 Mbps) |
| Audio bit rate: |
64 Kbps |
| Dual Stream: |
Support |
| Stream Type: |
Video/ Video & Audio |
| Network protocols |
|---|
| Protocols Supported: |
IPv4/v6, HTTP, HTTPS, QoS layer3 DiffServ, FTP, SMTP, Bonjour, UPnPTM,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, hkDDNS, NTP, RTSP, RTP/RTCP,TCP, UDP, IGMP, ICMP,DHCP, ARP, SOCKSv4/v5, PSIA, OnVIF, HIKCGI, netFilter |
| Data storage |
|---|
| Type: |
NAS, IPSAN, microSD |
| Capacity: |
Up to 4 TB capacity for each disk, and 32GB for microSD storage |
| External interface |
|---|
| Network interface: |
1 RJ-45 10 M / 100 Mbps adaptive Ethernet
interface (PoE) |
| Serial interface: |
1 RS-485
1 RS-485, 1 RS-232 |
| Alarm in: |
1
4 |
| Alarm out: |
1
2 |
| General |
|---|
| Power supply: |
12 VDC, or PoE |
| Consumption: |
≤ 6W
≤ 8W |
| Working temperature: |
-10°C~+55°C(14°F~131°F) |
| Working humidity: |
10%~90% |
| Dimension(W×D×H): |
80 × 39 × 90 mm
114 × 48 × 128 mm |
| Weight(without HDD): |
≤ 0.5 Kg
≤ 1 Kg |
