| Model | IDG 1600 |
|---|
| Input |
|---|
| Rated power |
1000 VA |
| Voltage |
177-300 Vac |
| Voltage tolerance |
240 Vac (+ / - 25%) |
| Frequency |
50/60 Hz auto sensing |
| Output and Inverter Output |
|---|
| Output Voltage |
220, 230, 240 LCD Selectable |
| Output Voltage Regulation |
Nominal Voltage + / - 5% |
| Frequency |
50 - 60 Hz + / - 0.1 Hz |
| Wave form - AC Mode |
Pure Sinewave |
| Wave form - Battery Mode |
Pure Sinewave - Entire battery range |
| Transfer Time |
2-4ms |
| Load crest factor |
3:1 |
| 10A Aust Outlets |
4 |
| Batteries |
|---|
| Type |
Maintenance-free sealed lead-acid |
| Number of Batteries |
2 x 12V 7.2 AH |
| Recharge Time |
90% within 4 Hours |
| Battery Start |
UPS can start without an AC Source |
| Automatic restart |
Restart after battery low and mains returns |
| Protection |
|---|
| Surge protection |
1600 Joules / 40,000 Amps |
| Input protection |
Compliance with IEEE 587 |
| Short circuit |
Resettable circuit breaker |
| Safety |
EN50091-1-1, CE |
| EMC |
EN50091-2, C Tick |
| Modem |
1 |
| Marks |
RJ45, Full time network protection |
| Comms & Management |
|---|
| Software |
Windows 95/98/NT/2000/XP/Vista/7, Windows Server 2003/2008 Linux Debian, Redhat, Fedora, Suse, Ubuntu, Centos, Novell, Mac, FreeBSD |
| Ports |
USB standard |
| Optional |
SNMP, RS232, Relay contact output, AS400 relay contact |
| LCD display |
UPS status, I/P & O/P voltage frequency, load %, battery voltage & %, temperature, model |
| LED display |
Normal (Green), back up (Yellow), fault (Red) |
| Audible alarm |
Alarm - on battery, overload, short circuit, over temperature, abnormal operation |
| Dimensions (h w d) |
270x93x310 mm |
| Minimum back up time with internal battery only |
5-12* min |
| Characteristics |
|---|
| Weight |
16 kgs |
| Width x Height x Depth (mm) |
440 x 88 (2RU) x 465 |
| Audible Noise |
< 40dB at 1 Metre |
| Temperature |
0-40°C |
| Humidity |
0-90% (non-condensing) |
| Runtime in Minutes |
|---|
| 100VA / 60W |
78 Minutes |
| 200 VA / 120W |
56 Minutes |
| 400 VA / 240W |
24 Minutes |
| 500 VA / 300W |
21 Minutes |
| 1000 VA / 600W |
6 Minutes |
