OPERATIONAL |
Operating system | Embedded Linux® |
IP camera | Input | 4 channels |
Supported codecs | H.265, H.264 |
Protocol | ONVIF |
Display | Speed | Up to 120fps |
Max. throughput | 80 Mbps |
Screen mode | Single channel, quad view mode, sequence |
Video – in | IP cameras (up to 4K, 3840 x 2160 resolution), Universal HD over Coax® VMAX® A1™ and VMAX A1 Plus™ DVRs or VMAX® IP Plus™ NVRs |
Video – out | Monitor | True HD and/or VGA |
Resolution | True HD: 3840x2160, 1920x1080, 1280x720, 1024x768
VGA: 1920x1080, 1280x720, 1024x768 |
LAN | 1x 10/100/1000 Base-TX Ethernet (RJ45) |
Protocols | TCP/IP (static, DHCP), DDNS and UPnP |
Network function | |
Time synchronization by NTP server |
Remote management | Web (IE) | System settings |
System recovery after power failure | Auto-reboot and log file system |
Advanced functions | Firmware upgrade by USB and CMS |
Import and export settings |
Warning alarm for system over-heating |
Digital zoom |
System operation | USB mouse |
ENVIROMENTAL |
Power | DC12V, 1A |
Operating temperature | 41°F ~ 104°F (5°C ~ 40°C) |
Operating humidity | 20–90% RH (non–condensing) |
Dimensions | 5.47" x 4.84" x 1.25" Inch (139 x 123 x 32 mm) |
| Warranty | 3 year warranty |
