Image sensor
|
4K 1/2.8” CMOS
|
|
Total pixels
|
3864(H) x 2228(V)
|
|
Active pixels
|
3840 (H) X 2160 (V)
|
|
Minimum scene illumination
|
0.12 lux (color)
|
|
0.0 lux (B/W)
|
|
S/N ratio
|
50dB
|
|
Test Monitor Video Output
|
Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
|
|
LENS
|
|
Focal length
|
2.8mm, F2.0
|
|
Lens type
|
Fixed lens
|
|
HFoV / VFoV
|
105.5° / 56.3°
|
|
IR distance
|
100ft range
|
|
I/O
|
|
Audio in / out
|
1 input / 1 output
|
|
Audio compression
|
G.711
|
|
Alarm in / out
|
1 input / 1 output
|
|
OPERATIONAL
|
|
Intelligent Video Analytics
|
IVA license: intrusion, line crossing, counting line, loitering, enter, exit, tamper
|
|
IVA+ license: object removed, tailgating, direction, stopped, appear, disappear, object left
|
|
Shutter mode
|
Auto, manual, anti-flicker, slow shutter
|
|
Shutter speed
|
1/15 ~ 1/32,000
|
| Slow shutter |
1/2,1/3,1/5,1/6,1/7.5, 1/10 |
|
Auto gain control
|
Auto
|
|
Day / night
|
Auto, day (color), night (B/W)
|
|
Smart DNR™ 3D digital noise reduction
|
3D DNR
|
|
Wide dynamic range (WDR)
|
True WDR (D-WDR) On, Off
|
| Wide dynamic range (WDR) dB |
120dB |
| Privacy zones |
16 programmable privacy masks |
| Mirror and flip |
Yes |
|
Alarm notifications
|
Notifications via e-mail, FTP and alarm output
|
|
NETWORK
|
|
LAN
|
RJ45 (10/100Base-T)
|
|
Video compression type
|
H.265, H.264, MJPEG
|
|
Resolution
|
H.265: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF
H.264: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF
MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF
|
|
Frame rate
|
Up to 30fps at all resolutions
|
|
Video bitrate
|
100Kbps ~ 10Mbps, multi-rate for preview and recording
|
|
Bitrate control
|
Multi-streaming CBR/VBR at H.265 (controllable frame rate and bandwidth)
|
|
Streaming capability
|
Dual-stream at different rates and resolutions
|
|
IP
|
IPv4
|
|
Protocol
|
TCP/IP, UDP, AutoIP, RTP (UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3 (MIB-2), ONVIF
|
|
Security
|
HTTPS(TLS), IP filtering, 802.1x, digest authentication(ID/PW)
|
|
ONVIF conformance
|
Yes
|
|
Web viewer
|
OS: Windows®, Mac® OS, Linux®
Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari®
NOTE: Chrome browser is recommended for IVA configuration.
|
|
Video management software
|
DW Spectrum® IPVMS
|
|
ENVIRONMENTAL
|
|
Operating temperature
|
-4°F ~ 122°F (-20°C ~ 50°C)
|
|
Operating humidity
|
10–90% RH (non–condensing)
|
| IK rating |
IK9 impact resistant |
|
IP rating
|
IP66-rated
|
|
Other certifications
|
CE, FCC, RoHS
|
|
ELECTRICAL
|
|
Power requirement
|
DC12V, PoE IEEE 802.3af Class 3 (Adapter not included)
|
|
Power consumption
|
|
|
MECHANICAL
|
|
Material
|
Aluminum vandal ball housing
|
|
Dimensions
|
4.92" x 4.4" (125 x 112mm)
|
|
Weight
|
1.87 lbs (0.85kg)
|
| Warranty |
3 year warranty |
