| System Parameters |
|---|
| Operation System: | Embedded Linux Operation System |
| Flash: | 32MB |
| Memory: | 128MB |
| Display Parameters |
|---|
| Display Screen: | 7-inch colourful IPS LCD |
| Display Resolution: | 1024 × 600 |
| Operation Method: | Capacitive Touch Screen, Physical Button |
| Audio Parameters |
|---|
| Audio Input: | Built-in Omnidirectional Microphone |
| Audio Output: | Built-in Loudspeaker |
| Audio Compression Standard: | G.711 U |
| Audio Compression Rate: | 64 Kbps |
| Audio Quality: | Noise Suppression and Echo Cancellation |
| Network Parameters |
|---|
| Wired network: | 10/100 Mbps self-adaptive network |
| Network Protocol: | TCP/IP, SIP, RTSP |
| Network interface: | 1 RJ-45 10/100 Mbps self-adaptive |
| Device Interfaces |
|---|
| I/O Output: | 2 |
| Alarm Input: | 8-ch alarm inputs |
| RS-485: | Supported |
| TF Card (micro SD card): | Max to 32 G, SD 2.0 or lower version |
| General |
|---|
| Power Supply: | IEEE802.3af standard PoE, 12 VDC/1A |
| Power Supply via Detector: | 12 V, 200 mA |
| Power Consumption: | ≤7W |
| Working Humidity: | 10% to 90% |
| Working Temperature: | -10° C to + 55° C (14° F to 131° F) |
| Mounting: | Surface mounting |
| Certification: | FCC, IC, CE, C-TICK, ROHS, REACH, WEEE, UL, CB, RCM |
