| Channel No. | 8 channels |
| Recording Resolution | 16MP;12MP;8MP;6MP;5MP;4MP;3MP;1080p;960p;720p;D1;CIF |
| Incoming/Outgoing Bandwidth | 160Mbps incoming, 160Mbps outgoing |
| Decoding Capability | AI disabled: 2×12MP@30fps; 4×8MP@30fps; 8×4MP@30fps; 16×1080p@30fps; AI enabled: 2×12MP@30fps; 4×6MP@30fps; 8×3MP@30fps; 14×1080p@30fps |
| Video Output | 1 HDMI, 1 VGA Simultaneous： HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
| Audio I/O | 1/1 |
| Video Compression | Smart H.265; H.265; Smart H.264; H.264 |
| Storage Capacity | 2 SATA port, Up to 12TB per disk, HDD sold separately |
| AI by Recorder | 4-ch(SMD) |
| AI by Camera | 8-ch(SMD, intrusion, tripwire, face capture) |
| Network | 1×RJ-45 10/100/1000 Mbps Ethernet port |
| PoE Port | 8 ports, 10/100 Mbps, IEEE 802.3 af/at |
| USB Port | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| Product Dimension | 375mm×329.4mm×54mm(14.76"×12.97"×2.13") |
| Working Temperature/Humidity | -10°C ~ 55°C (14°F ~ 131°F), humidity, ≤95% RH (non-condensing) |
| Power Supply | 52 VDC, 2.3 A |
| Power Consumption | <10W，without HDD |
