| Channel No. | 4 channels |
| Recording Resolution | 12MP;8MP;6MP;5MP;4MP;3MP;1080p;960p;720p;D1;CIF |
| Incoming/Outgoing Bandwidth | 80Mbps incoming, 80Mbps outgoing |
| Decoding Capability | AI disabled: 1×12MP@30fps; 2×8MP@30fps; 4×4MP@30fps; 8×1080p@30fps AI enabled: 1×12MP@30fps; 1×8MP@30fps; 4×3MP@30fps; 6×1080p@30fps |
| Video Output | 1 HDMI, 1 VGA Simultaneous： HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720 |
| Audio I/O | 1/1 |
| Video Compression | Smart H.265; H.265; Smart H.264; H.264 |
| Storage Capacity | 1 SATA port, Up to 12TB per disk, HDD sold separately |
| AI by Recorder | 2-ch(SMD) |
| AI by Camera | 4-ch(SMD, intrusion, tripwire, face capture) |
| Network | 1×RJ-45 10/100 Mbps Ethernet port |
| PoE Port | 4 ports, 10/100 Mbps, IEEE 802.3 af/at |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| Product Dimension | 250mm×232.2mm×47.9mm(9.84"×9.14"×1.89") |
| WorkingTemperature/Humidity | -10°C ~ 55°C (14°F ~ 131°F), humidity, ≤95% RH (non-condensing) |
| Power Supply | 52 VDC, 1.2 A |
| Power Consumption | <10W，without HDD |
