| Image Sensor | 1/2.7″ Progressive Scan CMOS |
| Max. Resolution | 3840×2160(8MP) |
| Min. Illumination | Color: 0.004 Lux@(F1.3,AGC ON),0 Lux with light |
| Angle Adjustment | Pan: 0°to 360°, Tilt: 0°to 90°, Rotate: 0°to 360° |
| Focal Length | Varifocal lens 2.7-13.5mm |
| Field of View | Wide: H:112.2°,V: 58.2°,D: 137.2° Tele: H:35.3°,V: 19.9°,D: 40.5° |
| Illumination Distance | IR up to 40m, white light up to 40m |
| Video Compression | Smart H.264/H.264, Smart H.265/H.265 |
| Streaming Capability | 3 streams |
| Wide Dynamic Range | 130dB |
| Storage | FTP; Micro SD card (support max. 512 GB) |
| Smart Function | Smart Motion Detection(SMD), Intrusion, Tripwire (support the classification and accurate detection of vehicle and human) People counting,heatmap Face Capture |
| Built-in Mic | Support |
| Built-in Speaker | Support |
| Operating Temperature | -30°C ~ 60°C (-22°F ~ 140°F) |
| Power Supply | 12 VDC ± 25%;PoE,IEEE 802.3af |
| Humidity | ≤95% RH (non-condensing) |
| Indoor/Outdoor | Outdoor |
| Protection Level | IP67 |
