IMAGE |
Image sensor | 4K 1/2.8” CMOS |
Total pixels | 3952 (H) x 2320 (V)
|
| Active pixels | 3840 (H) X 2160 (V)
|
Minimum scene illumination | 0.018 lux (color) |
0.0 lux (B/W) |
Test Monitor Video Output
| Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio |
LENS |
Focal length | 2.8mm, F2.0
|
Lens type | Fixed lens |
HFOV / VFOV | 105.5° / 56.3° |
IR distance | 100ft range |
I/O |
Audio in / out | 1 input / 1 output
|
Audio compression | G.711 |
Alarm in / out | 1 input / 1 output
|
OPERATIONAL |
Intelligent Video Analytics | IVA license (DWC-MVC8Wi28TW): intrusion, line crossing, counting line, loitering, enter, exit, tamper IVA+ license (DWC-MPVC8Wi28TW): object removed, tailgating, direction, stopped, appear, disappear, object left |
Shutter mode | Auto, manual, anti-flicker, slow shutter |
Shutter speed | 1/15 ~ 1/32,000 |
| Slow shutter | 1/2,1/3,1/5,1/6,1/7.5, 1/10 |
Auto gain control | Auto |
Day / night | Auto, day (color), night (B/W) |
Smart DNR™ 3D digital noise reduction | 3D DNR |
Wide dynamic range (WDR) | True WDR (D-WDR) On, Off |
| Wide dynamic range (WDR) dB | 120dB |
| Privacy zones | 16 programmable privacy masks |
| Mirror and flip | Yes |
Alarm notifications | Notifications via e-mail, FTP, alarm output and SD card recording |
Memory slot | Micro SD / SDHC / SDXC (card not included) |
NETWORK |
LAN | RJ45 (10/100Base-T) |
Video compression type | H.265, H.264, MJPEG |
Resolution | H.265: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF H.264: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF MJPEG: 2.1MP/1080p, 720p, 800x600, VGA, 768x432, D1, CIF |
Frame rate | Up to 30fps at all resolutions |
Video bitrate | H.264 / H.265 : 32Kbps ~ 14Mbps MJPEG : 1Mbps ~ 40Mbps |
Bitrate control | H.265 dual-stream or simultaneous H.265 / H.264 / MJPEG |
Streaming capability | Dual-stream at different rates and resolutions |
IP | IPv4, IPv6 |
Protocol | TCP/IP, UDP, AutoIP, RTP(UDP/TCP), RTSP, NTP, HTTP, HTTPS, SSL, DNS, DDNS, DHCP, FTP, SMTP, ICMP, SNMPv1/v2/v3(MIB-2), ONVIF |
Security | HTTPS(TLS), IP filtering, 802.1x, digest authentication(ID/PW) |
ONVIF conformance | Yes |
Web viewer | OS: Windows®, Mac® OS, Linux®
Browser: Internet Explorer®, Google Chrome®, Mozilla Firefox®, Safari®
NOTE: Chrome browser is recommended for IVA configuration. |
Video management software | DW Spectrum® IPVMS |
ENVIRONMENTAL |
Operating temperature | -4°F ~ 122°F (-20°C ~ 50°C) |
Operating humidity | 10–90% RH (non–condensing) |
| IK rating | IK10 impact-resistant |
IP rating | IP67-rated |
Other certifications | CE, FCC, RoHS  |
ELECTRICAL |
Power requirement | DC12V, PoE IEEE 802.3af Class 3 (Adapter not included)
|
Power consumption | DC12V: max 10W PoE: max 13W |
MECHANICAL |
Material | Aluminum vandal housing, polycarbonate dome, CleanView™ dome treatment |
Dimensions | 4.92" x 3.62" (125 x 92mm)
|
Weight | 1.14 lbs (0.52 kg)
|
| Warranty | 3 year warranty |
