Operating system
| Embedded Linux®
|
System
| Video compression | H.265, H.264 |
Channel
| 12 Channel (DW-PVX16W multi-sensor IP camera uses 4 channels in the recorder, one per sensor).
|
No. of PoE
| 8 Ch
|
Max supported resolution
| IP camera max. 4K (3840×2160) |
Communication protocol
| ONVIF®
|
PoE type
| 1Gbps, 802.3af
|
Display
| Speed
| 360fps
|
Screen mode
| 1, 4, 9 and 12
|
Video-out
| Monitor
| True HD and VGA
|
resolution
| 1024x768, 1280x720, 1280x1024, 1920x1080, 2560x1600, 3840×2160 (4K) |
Recording speed
| Up to 360fps up to 4K resolution |
Max. throughput
| 80 Mbps |
Max. HDD bay
| 4 x SATA HDD, up to 32TB |
Recording resolution
| Dual-stream
|
Recording modes
| Continuous, C+M, C+S, scheduled, sensor and motion detection recording
|
Pre-alarm recording, emergency recording, quick backup
|
Playback and search
| Speed
| x1, x2, x4, x8, x16, x32, x64, x100
|
Function
| Intelli-search by time bar, calendar (date and time) and event search
|
Audio output
| 1 Ch
|
Alarm input/relay output
| 4 Ch/ 1 Ch
|
PTZ control
| RS-485, ONVIF
|
Transaction verification
| TCP and USB-serial interface
|
LAN
| 1x gigabit ethernet (RJ45) – fixed IP, DHCP and DDNS
|
Access | Web viewer: Live, playback and configuration up to 10 multiple connections |
| Client monitoring software: Mac® (Apple® S/W), C3™ (CMS S/W) |
Compatible mobile apps:
|
Backup device
| Local backup by USB, network backup by CMS
|
System recovery after power failure
| Auto-reboot and journaling file system
|
Other function
| Firmware upgrade
| FTP, USB
|
Back-up
| Remote, USB
|
Special features
| Local PoE switch
Quick Setup under 3 minutes
Snapshot Notify™: Programmable interval camera image verification sent to an email
Event notifications via email, text and C3™ CMS and push notifications to mobile devices
Real-time temp alert
Digital Zoom in live and playback |
Health check | Real-time system, network and PoE status monitoring |
System operation
| IR remote controller (optional), USB mouse, PTZ control by keyboard (optional)
|
Power requirements
| 110~240V A/C |
| Total PoE Power Budget | 150W |
| Max. Power per Port | 30W |
Power consumption
| 360 W total power budget, 5.5A, 18.75W per PoE channel (simultaneous) |
Operating temperature and humidity
| 41~104 °F (5~40 °C) / 20~90% RH
|
Dimension (WxDxH)
| 17.32” x 15.66” x 2.79” (440 × 397.8 ×71 mm), 1.5U |
Certification
| CE, FCC, KCC, WEEE, RoHS
|
Warranty
| 3 year limited |
