IMAGE |
Image sensor | 5MP 1/2.7” CMOS |
Total pixels | 2592(H) X 1944 (V)
|
Minimum scene illumination | 0.02 lux (color) |
0.0 lux (B/W) |
S/N ratio | 50dB
|
LENS |
Focal length | 2.8mm, F1.6 (DWC-MV95Wi28TW)
3.6mm, F1.6 (DWC-MV95Wi36TW)
|
Lens type | Fixed lens |
Field of view (FoV) | 98.5° (DWC-MV95Wi28TW)
81.4° (DWC-MV95Wi36TW) |
IR distance | 100ft Range |
I/O |
Audio in/out | 1 audio input, 1 microphone built-in /1 output |
Audio compression | G.711A / U |
| Alarm in/out | 1 input / 1 output |
OPERATIONAL |
Shutter mode | Auto, manual |
Shutter speed | 1/30s ~ 1/100000s |
Auto gain control | Auto |
Day / night | Auto, day (color), night (B/W), schedule |
Smart DNR™ 3D digital noise reduction | 3D DNR |
Wide dynamic range (WDR) | True WDR low, middle, high |
Wide dynamic range (WDR) dB | 120dB |
Privacy zone | 4 programmable privacy masks |
Camera analytics | Line crossing, perimeter intrusion, video tampering detection (scene change, video blur, abnormal color detection), object classification (differentiate humans from objects) |
Alarm notifications | Notifications via e-mail or FTP server |
| Memory slot | Micro SD / SDHC / SDXC (card not Included) |
NETWORK |
LAN | 802.3 compliance 10/100 LAN |
Video compression type | H.265. H.264, MJPEG |
Resolution | 5MP, 4MP, 2K, 3MP, 2.1MP/1080P, 720P (60Hz: 1 ~ 30fps; 50Hz: 1~25fps) HFR mode: 1080P / 720P (60Hz: 1 ~ 60fps; 50Hz: 1~50fps) |
Frame rate | Up to 30fps at all resolutions |
Video bitrate | 64 Kbps ~ 8 Mbps |
Bitrate control | Multi-streaming CBR/VBR at H.264/ H.265 (controllable frame rate and bandwidth) |
Streaming capability | Dual-stream at different rates and resolutions |
IP | IPv4, IPv6 |
Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS
|
Security | IP filtering, MAC filtering, authentication (ID/PW), SSL/TSL |
ONVIF conformance | Yes |
Web viewer | OS: Windows® Browser: Internet Explorer |
Video management software | DW Spectrum® IPVMS |
ENVIRONMENTAL |
Operating temperature | -22°F ~ 140°F (-30°C ~ 60°C) |
Operating humidity | 95% RH (non–condensing) |
IP rating | IP67-rated |
IK rating | IK10 impact-resistant |
Other certifications | CE, FCC, RoHS |
ELECTRICAL |
Power requirement | DC 12V, PoE IEEE 802.3af Class 3. (Adapter not included)
|
Power consumption | 6W |
MECHANICAL |
Material | Metal vandal housing, polycarbonate dome |
Dimensions | 4.59" x 3.54" (116.6x 90 mm)
|
Weight | 1.43 lb (0.65 kg) |
| Warranty | 3 year warranty |
