Image sensor
|
5MP 1/2.7” CMOS
|
|
Total pixels
|
2592 (H) x 1944 (V)
|
|
Minimum scene illumination
|
0.02 lux (color)
|
|
0.0 lux (B/W)
|
|
S/N ratio
|
50dB
|
|
LENS
|
|
Focal length
|
2.8mm, F1.6 (DWC-MT95Wi28TW)
3.6mm, F1.6 (DWC-MT95Wi36TW)
|
|
Lens type
|
Fixed lens
|
|
Field of view (FoV)
|
98.5° (DWC-MT95Wi28TW)
81.4° (DWC-MT95Wi36TW)
|
|
IR distance
|
100ft Range
|
|
I/O
|
|
Audio in/out
|
1 audio input and 1 microphone built-in / 1 output
|
|
Audio compression
|
G.711A / U
|
|
OPERATIONAL
|
|
Shutter mode
|
Auto, manual
|
|
Shutter speed
|
1/30s ~ 1/100000s
|
|
Auto gain control
|
Auto
|
|
Day / night
|
Auto, day (color), night (B/W), schedule
|
|
Smart DNR™ 3D digital noise reduction
|
3D DNR
|
|
Wide dynamic range (WDR)
|
True WDR low, middle, high
|
|
Wide dynamic range (WDR) dB
|
120dB
|
|
Privacy zone
|
4 programmable privacy masks
|
|
Camera analytics
|
Line crossing, perimeter intrusion, video tampering detection (scene change, video blur, abnormal color detection), object classification (differentiate humans from objects)
|
|
Alarm notifications
|
Notifications via e-mail or FTP server
|
| Memory slot |
Micro SD / SDHC / SDXC (card not Included) |
|
NETWORK
|
|
LAN
|
802.3 compliance 10/100 LAN
|
|
Video compression type
|
H.265. H.264, MJPEG
|
|
Resolution
|
5MP, 4MP, 2K, 3MP, 2.1MP/1080P, 720P
(60Hz: 1 ~ 30fps; 50Hz: 1~25fps)
HFR mode: 1080P / 720P
(60Hz: 1 ~ 60fps; 50Hz: 1~50fps)
|
|
Frame rate
|
Up to 30fps at all resolutions
|
|
Video bitrate
|
64 Kbps ~ 8 Mbps
|
|
Bitrate control
|
Multi-streaming CBR/VBR at H.264/ H.265 (controllable frame rate and bandwidth)
|
|
Streaming capability
|
Dual-stream at different rates and resolutions
|
|
IP
|
IPv4, IPv6
|
|
Protocol
|
UDP, IPv4, IPv6, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, 802.1x, UPnP, HTTPs, QoS
|
|
Security
|
IP filtering, MAC filtering, authentication (ID/PW), SSL/TSL
|
|
ONVIF conformance
|
Yes
|
|
Web viewer
|
OS: Windows® Browser: Internet Explorer
|
|
Video management software
|
DW Spectrum® IPVMS
|
|
ENVIRONMENTAL
|
|
Operating temperature
|
-22°F ~ 140°F (-30°C ~ 60°C)
|
|
Operating humidity
|
95% RH (non–condensing)
|
|
IP rating
|
IP67-rated
|
| IK rating |
IK 10 impact-resistant |
|
Other certifications
|
CE, FCC, RoHS
|
|
ELECTRICAL
|
|
Power requirement
|
DC 12V, PoE IEEE 802.3af Class 3. (Adapter not included)
|
|
Power consumption
|
7W
|
|
MECHANICAL
|
|
Material
|
Metal turret housing
|
|
Dimensions
|
4.66" x 3.58" (118.6 x 91 mm)
|
|
Weight
|
1.01 lb (0.46 kg)
|
| Warranty |
3 year warranty |
