2.8 mm, horizontal FOV 96°, vertical FOV 52°, diagonal FOV 113°
4 mm, horizontal FOV 76°, vertical FOV 41°, diagonal FOV 89°
6 mm, horizontal FOV 50°, vertical FOV 27°, diagonal FOV 58°
2.8 mm: 2 m to ∞
4 mm: 2.7 m to ∞
6 mm: 5.9 m to ∞
2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m
4 mm, D: 82 m, O: 32 m, R: 16 m, I: 8 m
6 mm, D: 120 m, O: 47 m, R: 24 m, I: 12 m
50 Hz: 12.5 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 15 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
50 Hz: 12.5 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360)
Main stream: H.265/H.264,
Sub-stream: H.265/H.264/MJPEG,
H.264+ and H.265+: main stream supports under performance mode
Up to 32 users
3 user levels: administrator, operator, and user
Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Up to 1000 m
(The performance varies based on actual environment)
Built-in eMMC storage, up to 64 GB,Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
With -H: -20 °C to 50 °C (-4 °F to 122 °F). Humidity 95% or less (non-condensing),
Without -H: 0 °C to 60 °C (32 °F to 140 °F). Humidity 95% or less (non-condensing)
With -H:
Charging: -20 °C to 45 °C (-4 °F to 113 °F)
Discharging: -20 °C to 60 °C (-4 °F to 140 °F)
Without -H model:
Charging: 0 °C to 45 °C (32 °F to 113 °F)
Performance mode: 3.6 days,
Proactive mode: 6 days,
Standby mode: 30 days
CE-EMC: EN 55032:2015+A11:2020+A1:2020 EN 50130-4:2011+A1:2014; RCM: AS/NZS CISPR 32: 2015
CB IEC: 62368-1:2014; CE-LVD: EN 62368-1: 2014+A11: 2017; LOA: SANS IEC 60950
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
