| Camera |
|---|
| Image Sensor: | 2× 1/2.8" progressive scan CMOS |
| Effective Pixels: | 1920(H)x1080(V) |
| Signal System: | PAL/NTSC |
| Minimum Illumination: | Color: 0.0004 Lux @(F1.5, AGC ON)
B/W: 0.0001 Lux @(F1.5, AGC ON)
0 Lux with IR |
| AGC: | Auto/Manual |
| BLC: | ON/OFF |
| HLC: | Support |
| Smart defog: | Support |
| WDR: | 120dB |
| Shutter Time: | 50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s |
| Day& Night: | ICR |
| Digital Zoom: | 16X |
| Privacy Mask: | 24 programmable privacy masks |
| Auto Focus: | Auto / Semi-automatic / Manual |
| Rapid Focus: | Yes |
| Lens |
|---|
| Focal Length: | 4.8 mm to 120 mm, 25× Optical |
| Zoom Speed: | Approx. 4.4 s (optical lens, wide-tele) |
| Field of View: | Horizontal field of view: 58.2° to 3.2° (wide-tele)
Vertical field of view: 32.7° to 1.8° (wide-tele)
Diagonal field of view: 66.8° to 3.7° (wide-tele) |
| Minimum Working Distance: | 10-1500mm(Wide-Tele) |
| Aperture Range: | F1.5~F3.5 |
| Pan & Tilt |
|---|
| Pan Range: | 360°endless |
| Pan Speed: | Configurable, from 0.1°/s to 210°/s, Preset Speed: 280°/s |
| Tilt Range: | -20°~90°(Auto Flip) |
| Tilt Speed: | Configurable, from 0.1°/s to 150°/s, Preset Speed: 250°/s |
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: | 300 |
| Patrol: | 8 patrols, up to 32 presets per patrol |
| Pattern: | 4 patterns, with the recording time not less than 10 minutes per pattern |
| Power-off Memory: | Support |
| Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: | ON/OFF |
| Smart-tracking: | Manual Tracking, Auto Tracking (support tracking specified target types such as human and vehicle), Event Tracking |
| Wiper: | Optional |
| Infrared |
|---|
| IR Distance: | 200m |
| IR irradiation angle: | Adjustable by zoom |
| Alarm |
|---|
| Alarm Input: | 7 Inputs |
| Alarm Output: | 2 |
| Alarm Linkage: | Preset, Patrol, Pattern, Micro SD/SDHC card recording, Relay output, Notification on Client, Send Email, Upload to FTP, Trigger Channel |
| Network |
|---|
| Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector |
| Main Stream: | 50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
| Sub Stream: | 50Hz: 25fps(704×576, 640x480,352×288); 60Hz: 30fps(704×480, 640x480,352×240) |
| Third Stream: | 50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480, 320 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480, 320 × 240) |
| Video Compression: | Main Stream: H.265+/H.265/H.264+/H.264
Sub-Stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG |
| ROI encoding: | Eight fixed region for each stream |
| Audio Compression: | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Audio Mode: | OFF/Audio input/Audio output |
| Simultaneous Live View: | Up to 20 channels |
| Three-Stream: | Support |
| Storage: | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB |
| Security Measures: | User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering |
| Client GUI |
|---|
| Camera Control: | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Date & Time Display: | Time: Week: Date, 6 formats on the Client |
| Client: | Support iVMS-4200 |
| Web Browser: | IE 7+, Chrome 18 - 42, Firefox 5.0 +, Safari 5.02 + |
| General |
|---|
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power Supply: | 24 VAC & Hi-PoE |
| Power Consumption: | Without wiper: 24 VAC, max. 68 W (max. 12 W for heater, and max. 15 W for IR), Hi-PoE, max. 60 W
With wiper: 24 VAC max. 70 W (max. 12 W for heater, and max. 15 W for IR), Hi-PoE, max. 60 W |
| Working Temperature/Humidity: | Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: ≤ 90% |
| Protection Level: | IP67 Standard. Lightning protection, surge protection and voltage transient protection meets IEC61000-4-2-2/3/4/5/6 |
| Dimensions: | Φ 266.6 mm × 437 mm (Φ 10.50" × 17.20") |
| Weight (approx.): | 8kg (approx.17.64lb) |
