| System Parameters |
|---|
| Processor: |
High-Performance Embedded SOC Processor |
| Operation System: |
Embedded Linux Operation System |
| Memory: |
256M |
| Display Parameters |
|---|
| Display Screen: |
7-Inch Colorful TFT LCD |
| Display Resolution: |
1024 × 600 |
| Operation Method: |
Capacitive Touch Screen, Touch Key |
| Operation interface: |
Flattened UI Operation Interface |
| Audio Parameters |
|---|
| Audio Input: |
Built-in Omnidirectional Microphone |
| Audio Output: |
Built-in Loudspeaker |
| Audio Compression Standard: |
G.711 U |
| Audio Compression Rate: |
64 Kbps |
| Audio Quality: |
Noise Suppression and Echo Cancellation |
| Network Parameters |
|---|
| Ethernet: |
10/100 Mbps Self-Adaptive Ethernet |
| Network Protocol: |
TCP/IP, RTSP |
| Alarm Parameters |
|---|
| Alarm Input: |
8-ch Alarm Input Sensor |
| Device Interfaces |
|---|
| Network Interface: |
1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| RS-485: |
1 RS-485 Half-Duplex Port |
| I/O Output: |
2 |
| TF Card (micro SD card): |
TF Card, Support Max. 32GB |
| General |
|---|
| Power Supply: |
12 VDC/24 VDC, Power Over Network Cable (DS-KAD606, DS-KAD612) |
| Power Consumption: |
≤10 W |
| Working Temperature: |
-10° C to + 55° C (14° F to 131° F) |
| Working Humidity: |
10% to 90% |
| Dimensions(L × W × H): |
217 mm × 142 mm × 26 mm (8.5" × 5.6" × 1.0") |
| Certification: |
FCC, IC, CE, C-TICK, ROHS, REACH, WEEE |
