| Camera |
|---|
| Image Sensor: | 1/2.8" Progressive Scan CMOS |
| Effective Pixels: | 1920(H)x1080(V) |
| Signal System: | PAL/NTSC |
| Minimum Illumination: | Color : 0.3 lux (F1.6,1/30 sec, 50 IRE, AGC On)
B/W : 0.02 lux (F1.6,1/30 sec, 50 IRE, AGC On)
0 lux with IR
Color : 0.02 lux (F1.6, 1/1 sec, 50 IRE, AGC On)
B/W : 0.002 lux (F1.6, 1/1 sec, 50 IRE, AGC On)
0 lux with IR |
| White Balance: | Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC: | Auto/Manual |
| S/N Ratio: | ≥ 55dB |
| BLC: | ON/OFF |
| HLC: | Support |
| Smart defog: | Support |
| WDR: | Support |
| Shutter Time: | 50Hz: 1-1/30,000s
60Hz: 1-1/30,000s |
| Day& Night: | ICR |
| Digital Zoom: | 16X |
| Privacy Masking: | 24 privacy masks programmable; optional multiple colors and mosaics |
| Auto Focus: | Auto / Semi-automatic / Manual |
| Lens |
|---|
| Focal Length: | 4.3-129mm, 30x |
| Zoom Speed: | Approx.3s(Optical Wide-Tele) |
| Angle of View: | 65.5-2.11 degree (Wide-Tele) |
| Minimum Working Distance: | 10-1500mm(Wide-Tele) |
| Aperture Range: | F1.6-F5.0 |
| Pan & Tilt |
|---|
| Pan Range: | 360°endless |
| Pan Speed: | Pan Manual Speed: 0.1°-160°/s,
Pan Preset Speed: 240°/s |
| Tilt Range: | -2°-90° (Auto Flip ) |
| Tilt Speed: | Tilt Manual Speed: 0.1°-120°/s,
Tilt Preset Speed: 200°/s |
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset: | 300 |
| Patrol: | 8 patrols, up to 32 presets per patrol |
| Pattern: | 4 patterns, with the recording time not less than 10 minutes per pattern |
| Power loss recovery: | Support |
| Park Action: | Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan |
| PTZ Position Display: | ON/OFF |
| Freeze Frame: | Support |
| Smart-tracking: | Manual/ Panorama/ Intrusion trigger/ Line crossing trigger / Region entrance trigger / Region exiting trigger |
| Infrared |
|---|
| IR irradiation distance: | 150m |
| IR irradiation angle: | Adjustable by zoom |
| Alarm |
|---|
| Alarm Input: | 7 Inputs |
| Alarm Output: | 2 |
| Alarm Actions: | Preset, patrol, pattern, SD/SDHC card recording, relay output, notifi cation on client |
| Input & Output |
|---|
| Monitor Output: | 1.0Vp-p / 75Ω, NTSC (or PAL) composite, BNC |
| Audio Input: | 1 Mic in/Line in interface
Line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10% |
| Audio Output: | 1 Audio output interface
Line level, impedance: 600Ω |
| Network |
|---|
| Ethernet: | 10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: | 1920×1080 |
| Main Stream: | 50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720) |
| Sub Stream: | 50Hz: 25fps(704×576), 25fps (352×288), 25fps (176×144)
60Hz: 30fps(704×480), 30fps (352×240), 30fps (176×120) |
| Third Stream: | 50Hz: 25fps(1920×1080), 25fps(1280×960), 25fps (1280×720), 25fps(704×576), 25fps (352×288), 25fps (176×144)
60Hz: 30fps(1920×1080), 30fps(1280×960), 30fps (1280×720), 30fps(704×480), 30fps (352×240), 30fps (176×120) |
| Image Compression: | H.264/MJPEG/MPEG4, H.264 encoding with Baseline/Main/High profile |
| ROI encoding: | Support 24 areas with adjustable levels |
| Audio Compression: | G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Protocols: | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| No. of Simultaneous Users: | Up to 20 users |
| Three-Stream: | Support |
| Mini SD Card: | Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording |
| User/Host Level: | Up to 32 users,3 Levels: Administrator, Operator and User |
| Security Measures: | User authentication (ID and PW),
Host authentication (MAC address)
IP address filtering |
| Client GUI |
|---|
| Camera Control: | Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Date & Time Display: | Time: Week: Date, 6 formats on the Client |
| Client: | Support iVMS-4200 |
| Web Browser: | IE 7+, Chrome 18 +, Firefox 5.0 +, Safari 5.02 +, support multi-language |
| General |
|---|
| RS-485 Protocols: | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Menu Language: | English / Chinese |
| Power Supply: | 24 VAC & Hi-PoE |
| Power Consumption: | 24 VAC: 60W max(heater: 45W)
Hi-PoE: 50W max(heater: 20W) |
| Working Temperature/Humidity: | 24 VAC: -40 ℃-65℃(-40℉-149℉)(outdoor dome)
Hi-PoE: -30 ℃-65℃(-22℉-149℉)(outdoor dome)
90% or less |
| Protection Level: | IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Mounting: | Various mounting modes optional |
| Dimensions: | Φ245×399mm (Φ9.65”×15.71”)(Outdoor) |
| Weight (approx.): | 6Kg (13.22 Ibs) |
| Mount Option: | Long-arm wall mount: DS-1602ZJ;Corner mount: DS-1602ZJ-corner; Pole Mount: DS-1602ZJ-pole; Power box mount:DS-1602ZJ-box |
