| Camera |
|---|
| Image Sensor: | 1/3" Progressive Scan CMOS |
| Min. Illumination: | 0.01Lux @(F1.2,AGC ON), 0.028Lux @(F2.0,AGC ON), 0 Lux with IR |
| Shutter time: | 1/3 s ~ 1/10,000 s |
| Slow shutter: | Support |
| Lens: | (-I3: 4,6mm; -I5: 4,6,12mm; -I8: 6,12,16mm) @F2.0 |
| Lens Mount: | M12 |
| Day & Night: | IR cut filter with auto switch |
| Wide Dynamic Range: | 120 dB |
| Digital noise reduction: | 3D DNR |
| Compression Standard |
|---|
| Video Compression: | H.264/MJPEG/H.264+ |
| H.264 code profile: | Main Profile |
| Video bitrate: | 32Kbps~16Mbps |
| Image |
|---|
| Max. Image Resolution: | 2688 × 1520 |
| Frame Rate: | 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720) |
| Image Enhancement: | BLC/3D DNR/ROI |
| Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Day/Night Switch: | Auto/Schedule/Triggered by Alarm In |
| Network |
|---|
| Network Storage: | NAS (Support NFS, SMB/CIFS) |
| Alarm Trigger: | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security: | Flash-prevention, dual-stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| System Compatibility: | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Interface |
|---|
| Communication Interface: | 1 RJ45 10M/100M/1000M Ethernet port |
| General |
|---|
| Operating Conditions: | -30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: | 12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: | I3: Max. 6W; I5: Max. 7.5W; I8: Max. 10.5W |
| Weather Proof: | IP66 |
| IR Range: | I3: 30 meters; I5: 50 meters; I8: 80 meters |
| Dimensions: | 299.71 × 86.48 × 85.11(11.8’’ × 3.4’’ × 3.35’’) |
| Weight: | 1200g (2.65 lbs) |
